Manual
Applicable for: Qube XL
Product-No.:
103-301-03-001-00 (white)
103-301-04-001-00 (black)
103-301-02-001-00 (oak)
103-301-01-001-00 (walnut)
103-301-05-001-00 (stone pine)
Specifications
24V (scope of delivery: power
Power Supply
supply with 24V / 2.5A)
Rated Power
(woofer and tweeter)
SPL 1W/1m
SPL max
40 Hz – 28 kHz (@1W/81dB)
Frequency Range (-3 dB)
100 Hz – 28 kHz (@30W/96dB)
Transmission Angle
1/2/4/8 kHz (-6 dB)
Protocols
W-LAN(b/g/n), LAN (100Mbit),
Connections
Dimensions (H/W/D)
Weight (alu / wood)
Material
Aluminum housing / real wood
with fabric trim (variants each)
Note:
! Please note the country-specific safety guidelines for use and operation
of W/LANs.
! For continued flawless audio transmission you should always use a
wireless router from 802.11n and the latest smartphones / tablets.
Product registration and extended warranty at:
www.whd.de/Produktregistrierung
This product supports all CE-
marking criteria. The declaration of
conformity certificate can be ob-
tained from WHD.
Operation
Thank you for buying our W/LAN 2way active hifi speaker.
Please read this manual carefully, especially the safety and security information.
Mounting the speaker
with wall bracket WH QB 300:
- Screw the wall bracket to the wall.
- remove the blind plugs from the housing and screw the bracket counterpart to the loudspeaker.
- Put on the speaker with the counterpart.
- Align it in the desired position and fix it with the retaining screw.
Operating modes of the Qube XL
- Stand alone operation, wired: with external audio source (AUX In) as single speaker or as stereo
zone with a second Qube XL (AUX Out left) / Operation: via audio source
Qube XL
- Bluetooth (activation within 3 minutes after switching on!) / Operation: via audio source
- LAN / WLAN (Direct Play / Multi Play) / Operation via WHD Multiroom APP
Connection of the speaker:
2x30 W
- Connect the enclosed power adapter (9) and the LAN (5).
- Turn on the Qube XL (7).
- If you connect an external source, use the 3.5mm jack Aux In (3) and set to Aux Auto (2).
81 dB
With a second Qube XL, you can build a stereo set by connecting the Aux Out Left (3) to the Aux
In (3) of the second Qube XL with a 3.5mm jack cable.
96 dB
The "Master" Qube XL plays the right audio channel and the "Slave" the left audio channel.
! Stereo operation is only possible with the Aux In (3) source. WLAN or Bluetooth will not trans-
fer to the second Qube XL.
- Select a suitable DSP preset (1) and set the maximum volume (4).
180/120/160/160 °
! If no RJ45 cable is connected, you have Wi-Fi operation.
Airplay, UPnP, DLNA
! If no audio signal is present at the AUX In, the AUX input can be deactivated via the switch (2)
(AUX off). In this way, possibly occurring noise (mains humming, etc.) can be prevented.
Bluetooth 4.0
! The Qube XL can also be connected to the network via WPS (Wi-Fi Protected Setup).
170x170x170 mm
3,0 / 2,1 kg
Keypad / on top
PAUSE/PLAY SKIP VOL- VOL+
ALL: white, bright
PLAY / PAUSE: Red, bright
PLAY / PAUSE: White, bright
Acoustic signals / network mode:
Easy audio signal signals Direct Play mode
Triple audio signal signals network
! In the speaker assistant in the WHD Multiroom app, the volume of
the beeps can be adjusted.
WHD are members of the INTERSEROH association.
We participate in the dual system as well as other
industry-specific solutions. Therefore, plastic, metal
and electronic parts can all be recycled.
Status
Status LED (8)
RED, bright
Operation
RED, blinking
Speaker in standby
Music is played
BLUE, brilliant
BLUE, blinking
DSP presets for the sound quality of the Qube XL
None = free lineup
Wall = Speaker is closer to a wall
Corner = speaker is in a corner
WHD - Wilhelm Huber+Söhne GmbH+Co.KG
Tel. Zentrale +49 74 20 / 8 89-0
Fax Zentrale +49 74 20 / 8 89-51
Version
(Technical and optical
modifications reserved)
18.09.2019
- Page 1 -
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8) (9)
Status
Connectable with WLAN / Direct Play
Not connectable (possibly restart or
RESET)
Connected to Wi-Fi, ready to receive
Boot process (about 30 seconds) or
firmware update (about 2 minutes)
Bismarckstr. 19
D-78652 Deißlingen
E-Mail:
info@whd.de
Web:
www.whd.de
