2.
Select the desired text color by enabling or disabling Dark Text. (This will make
the text white).
This feature affects only the text on the Classic (square) button home page.
Note:
Perform a Firmware Upgrade
1.
Insert an SD card in the HS2TCHP with the new firmware.
2.
Press Options, Installer Menu [Installer Code], Keypad Programming, then Firm-
ware Upgrade.
3.
Select OK to perform a firmware upgrade (if a new firmware version is available).

Keypad Programming

To enter keypad programming:
1.
Press Options then Keypad Mode. The virtual keypad is displayed.
2.
Press [*][8][Installer Code].
3.
Enter one of the following keypad programming sections:
[860] Keypad Slot Number. This section is for display only.
l
[861]-[876] to program keypads 1-16 respectively.
l
Once a keypad is selected, the following programming options are available:
[000] Keypad Partition Mask
Valid entriesare 00-08.
[011] Keypad Input/Output Programming
Zone or PGM Number Default 000
[012] Local PGM Output Pulse Activation Time
I___I___I Minutes (00-99)
[021] First Keypad Options
Default Value Option
ON I__I 1 Fire Key Enabled
ON I__I 2 Medical Key Enabled
ON I__I 3 Panic Key Enabled
Display Access Code When Pro-
ON I__I 4
gramming
[022] Second Keypad Options
Default Value Option
ON I__I 1 Local Clock Display ON
OFF I__I 2 Local Clock Displays 24-hr
|___|___|
I___I___I___I
I___I___I Seconds(00-99)
ON Off
Fire Key Disabled
Medical Key Disabled
Panic Key Disabled
Display Xs When Programming
Access Codes
ON Off
Local Clock Display OFF
Clock Displays AM/PM
Default Value Option
ON I__I 3 Auto Alarm Mem Scroll ON
ON I__I 4 For Future Use
OFF I__I 5 Power LED Enabled
Power LED Indicates AC Present
ON I__I 6
ON
ON I__I 7 Alarms Displayed While Armed
OFF I__I 8 Auto-Scroll Open Zones ON
Note:For UL/ULC installations, bit 5 (Power LED) and bit 6 (Power LED IndicatesAC Present)
shallbe ON.
[023] Third Keypad Options
Default Value Option
OFF I__I 1 Armed LED Power Save
ON I__I 2 Keypad Status Shows Stay Arm
5th Terminal is Keypad PGM Out-
OFF I__I 3
put
ON I__I 4 Prox tag will arm/disarm
OFF I__I 7 Local Display of Temperature
OFF I__I 8 Low Temperature Warning Enabled Low Temperature Warning Disabled
[030] Download LCD Messages
I___I___I___I___I___I___I___I___I___I___I___I___I___I ___I
I___I___I___I___I___I___I___I___I___I___I___I___I___I ___I
[031] Download LCD Message Duration
Default: 000 I___I___I___I
(Valid entriesare 000-255, 000=Unlimited Msg Display) Thisnumber representsthe number
of timesthe downloaded message must be cleared before it ispermanentlyremoved. This
message can be cleared bypressing anykey.
[041] Indoor Temperature Zone Assignment
Default: 000 I___I___I___I (Valid entries are 000-128)
[042] Outdoor Temperature Zone Assignment
Default: 000 I___I___I___I
[101] - [228] Door Chime for Zones 1 - 128
The keypad can be programmed to make up to four different chime soundsfor individual
zones(e.g., for Zone 1, enter section [101], for Zone 2 enter section [102]).
Default: 01 I___I___I
ON Off
Auto Alarm Mem Scroll OFF
For Future Use
Power LED Disabled
Power LED Indicates AC Present
OFF
Alarms Not Displayed While Armed
Auto-Scroll Open Zones OFF
ON Off
Armed LED Off in Sleep Mode
Keypad Status Shows Stay/Away
Arm
5th Terminal is Keypad Zone Input
Prox tag does not arm/disarm
No Local Display of Temperature
(Valid entries are 000-128)
