1. Functional Overview
Front – fig. 1
Display
Soft key
Soft key 2
Up/down selector
Left/right selector
Icon for system alarm
Icon for communication with Master Controller
Icon for switch to 230V power supply
Icon for low battery level
Note: The Remote Controller has a self-explanatory menu structure, and all settings are easily
carried out with the up/down and left/right selectors in combination with the functions of
the soft keys, which are shown above them in the display.
Back – fig. 2
Back plate/docking station
Battery compartment
Screw hole for wall mounting
Screw and wall plug
Transformer/power supply plug
Note: Remove the strip to connect the enclosed batteries.
VI.UH.M4.1C
4
CF-RC Remote Controller
Produced by Danfoss Floor Heating Hydronics 03.2007
