Wired device
Please note:
Thermostat 22-23006 Quantum can work without Universal Gateway or CO10RF Coordinator as a standalone
Wiring diagram for volt-free connection (e.g. boiler control):
1
L
N
Wiring diagram for 230VAC connections:
2
12
S1
S2
L N
COM NO
AC 230V
S1
S2
L
N
COM NO
AC 230V
L
N
BOILER CONNECTIO N *
S
MAX 3(1) A
