AXIS P5514-E PTZ Network Camera
Video
Medium
Large
It is also possible to display text when an action rule is triggered, see How to include overlay text in an action rule on page 20.
How to include overlay text
1. Go to Video > Video Stream and select the Image tab.
2. To include date and time, select Include date and Include time.
3. To include a text string, select Include text and enter the text in the field. Modifiers can be used, see File Naming &
Date/Time Formats in the online help
4. Select size, color, and placement of the text string.
5. Click Save.
To modify the date and time format, go to System Options > Date & Time. See Date & Time on page 44.

How to include overlay text in an action rule

Example
To display the text "Motion detected" when motion is detected, enter #D in the Include text field and enter "Motion detected" in
the Text field when setting up the action rule.
1. Go to Video > Video Stream and select the Image tab.
2. Under Overlay Settings, select Include text.
3. Enter the modifier #D. When the rule is triggered, #D is replaced by the text specified in the action rule.
Additional text in this field will be displayed also when the action rule is not active.
4. Go to Events > Action Rules and create your action rule.
5. From the Actions list, select Overlay Text.
6. Enter the text to display in the Text field.
7. Specify the Duration. The text can be displayed while the rule is active or for a fixed number of seconds.
How to display the pan or tilt position as a text overlay
It may be useful to retrieve, for instance from a recorded video, the pan or tilt position (in degrees) in which an event has taken
place. This can be obtained by including the position in the image as a text overlay, using a modifier. To display the pan position as a
text overlay:
1. Go to Setup > Video > Video Stream.
2. Under Overlay settings, select Include text.
Enter #x to show the pan position.
Enter #y to show the tilt position.
3. Configure the optional size, color and position of the text overlay.
4. Click Save.
5. Go to the Live View page to confirm the setting.
16 pixels
21 pixels
.
20
28 pixels
36 pixels
