CHANNEL MENU (SATELLITE)
Search [Blau]:
1. Use the [▲ ▼ ◄►] buttons to select a satellite or transponder that you want to scan.
2. Press the [OK] key to mark the satellite or transponder.
3. A red rake marks the selection.
4. Now press the [Blue] key to open the search settings.
5. Press [OK] when all the settings have been made to start the search.
The following setting options are available:
Scan Mode:
Channel Type:
Service Type:
Note:
The found channels are appended to the list.

LNB SETTINGS

The LNB settings on the right side of the
menu usually do not need to be changed and
are only required for multi-switch
configurations or if a motorized SAT system is
used without its own control unit. The
following setting options should only be
changed by experienced persons or by
qualified personnel.
Die folgenden Auswahl- und Einstellungsmöglichkeiten
stehen Ihnen in dem Menü zur Verfügung:
1. Navigate in the menu with the [▲ ▼] buttons.
2. Use the [◄►] button to adjust the settings.
3. Use the [OK] key to confirm the entry.
4. Press the [MENU] key to return to the previous menu.
5. Use the [EXIT] key to close the menu display.
LNB Type:
LNB Power:
22KHz:
Toneburst:
DISEqC 1.0:
DISEqC 1.1:
Motor:
Default / Network / FastScan
All Channels / FTA Channels
All / DTV / Radio
9750/10600, 9750/10750, 5150/5750, 05150, 05750, 09750,
10600, 10750, 11300, 11475, User Single, User Dual, Unicable
13/18V, 13V, 18V, Aus
Auto, Off, On
Kone, BurstA, BurstB
Kone, LNB1, LNB2, LNB3, LNB4
None, LNB1 – LNB16
None, DISEqC 1.2, DISEqC 1.3
