CONNECTIONS
Back of the device
DC:
VGA:
PC AUDIO
TV1 (S2) Satellite
TV2 (T2HD/C) Cabel
Antenna
COAX-S/PDIF
HDMI
USB Jack
EARPHONE
MINI YPbPr
MINI AV
CI+ SLOT
Power connection for the power supply.
Connection to use the TV as a PC monitor. Connect the D-
Sub 15Pin analog plug of your PC.
Connection for the PC audio output. Only usable in
combination with the VGA connection.
Connection of the satellite antenna.
Connection of the DVB-T antenna or cable system.
Digital output for external audio devices (such as AV
receivers, soundbars).
Connecting an external HDMI device (Blu-ray player, etc.)
Connection for USB sticks and hard disks.
Connection for headphones.
Connection of external AV device via adapter. Inputs are
shared with MINI AV.
Connection of external AV devices via adapter.
Slot for CI + modules for decrypting locked TV programs.
Module is not included.
