Troubleshooting - Logitech LS11 Schnellstartanleitung

3
Adjusting volume for the first time
1. Insert the 3.5 mm plug into the audio jack on your laptop, or soundcard.
2. Plug the power cord into an electrical outlet.
3. Using the control on the front of the right satellite, turn the LS11 on and adjust
the speaker volume.
4. Open your soundcard's mixer program.
Windows ® XP
• Go to the START menu, choose CONTROL PANEL, then SOUND
AND AUDIO DEVICES.
• Choose the AUDIO tab, select your SOUNDCARD as the SOUND
PLAYBACK DEVICE.
• Choose the VOLUME tab, adjust VOLUME SLIDER as necessary. The wave slider
should be on the highest setting. Do not select MUTE option.
• Select TEST HARDWARE tab to ensure proper installation.
Windows Vista ®
• Go to the START menu, choose CONTROL PANEL, choose CLASSIC VIEW,
choose SOUNDS.
• Choose the PLAYBACK tab, select your SOUNDCARD as the SOUND
PLAYBACK device if it is not already set as Default. Verify the SPEAKER ICON
is NOT muted.
• Perform test.
Mac OSX
®
• Go to SYSTEM PREFERENCES, Choose SOUND.
• Choose the OUTPUT tab, select your SOUNDCARD as the SOUND OUTPUT DEVICE, adjust the OUTPUT
VOLUME SLIDER to the desired level. Verify the MUTE box is unchecked.
4
English
620-001049 LS11_QSG_EMEA - Billie.indd 4-5 620-001049 LS11_QSG_EMEA - Billie.indd 4-5
4
1
Using headphones
Most types of analog headphones with a 3.5mm connector can be plugged into the headphone
jack on the front of the right speaker. When you plug in headphones, the speakers will be muted
automatically. To adjust the volume of your headphones, use the controls for your soundcard
or auxiliary sound source.
Headphone volume will not be affected by the LS11 volume control.
2
5
Using the auxiliary input
Devices such as portable CD players or MP3 players can be plugged into the 3.5mm AUX input jack
on the front of the right speaker using a 3.5mm auxilliary cable. Control the volume with the control
3
on the front of your LS11 speaker, or your auxiliary input source.

Troubleshooting

See below for solutions to common problems. If you have more questions about your Logitech
visit www.logitech.com/support
Speakers produce weak or no sound.
• Make sure the speakers are plugged into an electrical outlet. Turn the volume knob until it clicks and adjust
the volume. Try a different outlet.
• Try connecting the speakers to an alternate audio source – for example, a CD player, MP3 player, or radio.
If there is sound from the speakers, the problem is probably with your soundcard.
• Is the balance control centered in the Operating System (OS) audio mixer application?
One speaker doesn't produce sound.
• The audio plug must be securely inserted into the appropriate audio jacks.
• Is the soundcard balance control centered? Open your soundcard's mixer program as described in Section 3.
Adjust the balance control for equal volume on left and right.
® speakers,
5
English
