HOW TO USE THE MOBILIGHT
X
Attention! Please do not use
the Mobilight with spheres
only. Use only in combination
with the fresnel-lens!
1
SPOTS
MODE
2
WASH
MODE
3
FRESNEL
MODE
4
360°
MODE
+
RAIN
JACKET
4
In this position the fresnel lens must be on
top and all spheres in their place. Smooth
side of the fresnel lens points up.
EFFECT: 3 Spotlights
The diffusor should be in the center and the
fresnel lens with the smooth side up. Please
use the Fresnel-lens only in the upper third.
EFFECT:
Fading wash-light
The fresnel lens can be moved from top to
bottom. Left: Smooth side up, right: rough
side up. No spheres.
EFFECT: lights with strong edges
If you use the Mobilight without fresnel lens
and spheres, you get a 360° ambient light
EFFECT: 360° ambient light
Rain jacket is included in scope of delivery
and protects the Mobilight from rain and
weather.
EFFECT: Dry Mobilight
Fresnel-Lens: can be moved up and
down; has a smooth and a rough side to
achieve the effects described below.
li.: re.:
