Start-up
In the delivery state, the input is configured as
"push-button". The switching function can be
configured via the Homematic IP app.
• Fix the actuator to an appropriate flush-mounting
box. If required, remove the fixing lug (B) (see
figure 4).
• Close
appropriate cover.
• Switch the fuse of the power circuit on again to
activate the teach-in mode of the device (see
figure 6) (see "5.3 Teaching-in" on page 41).
5.2.2

Installation with surface-mounting box

To install the device in a surface-mounting box, proceed
as follows:
• Switch off the fuse of the power circuit (see figure
2).
Connect the actuator to L (C) and N (E) to obtain
•
power supply (see fig. 3).
• Route the switched phase (D) to the consumer
(see fig. 3).
• Connect an external push-button or switch to
connecting terminal S1 (B) (see figure 3).
In the delivery state, the input is configured as
"push-button". The switching function can be
configured via the Homematic IP app.
