Optional Accessories; Protecting The Environment - Forch F-ABS 10-2 Originalanweisungen

Operation as a Screwdriver
Select the desired speed/torque range using the
dual range gear shifter on the top of tool to match
the speed and torque to the planned operation.
Insert the desired fastener accessory into the
chuck as you would any drill bit. Make a few
practice runs in scrap or unseen areas to
determine the proper position of the clutch collar.
MAXIMUM RECOMMENDED CAPACITIES
Low Range–1
Bits, Metal
6.35 mm (1/4")
Drilling
Wood, Flat
19.05 mm (3/4") 12.7 mm (1/2")
Boring
Hole Saws 19.05 mm (3/4") 15.88 mm (5/8")
MAINTENANCE
Your FÖRCH power tool has been designed to
operate over a long period of time with a minimum
of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular
cleaning.
WARNING: To reduce the risk
of serious personal injury, place
the forward/reverse button in
the lock-off position or turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories.
The charger and battery pack are not serviceable.
There are no serviceable parts inside.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
WARNING: Blow dirt and dust out of
the main housing with dry air as often
as dirt is seen collecting in and around
the air vents. Wear approved eye
protection and approved dust mask
when performing this procedure.
WARNING: Never use solvents or
other harsh chemicals for cleaning the
non-metallic parts of the tool. These
CHARGER CLEANING INSTRUCTIONS
High Range–2
3.18 mm (1/8")

Optional Accessories

Protecting the Environment

Should you find one day that your FÖRCH product
needs replacement, or if it is of no further use to
you, do not dispose of it with household waste.
Make this product available for separate collection.
Local regulations may provide for separate
collection of electrical products from the household,
at municipal waste sites or by the retailer when you
purchase a new product.
FÖRCH provides a facility for the collection and
recycling of FÖRCH products once they have
reached the end of their working life. To take
advantage of this service please return your
product to any authorised repair agent who will
collect them on our behalf.
You can check the location of your nearest
authorised repair agent by contacting your local
FÖRCH office at the address indicated in this
manual.
chemicals may weaken the materials
used in these parts. Use a cloth
dampened only with water and mild
soap. Never let any liquid get inside
the tool; never immerse any part of the
tool into a liquid.
WARNING: Shock hazard. Disconnect
the charger from the AC outlet before
cleaning. Dirt and grease may be
removed from the exterior of the
charger using a cloth or soft non-
metallic brush. Do not use water or any
cleaning solutions.
WARNING: Since accessories, other
than those offered by FÖRCH, have
not been tested with this product, use
of such accessories with this tool could
be hazardous. To reduce the risk of
injury, only FÖRCH, recommended
accessories should be used with this
product.
Separate collection. This product
must not be disposed of with normal
household waste.
Separate collection of used products
and packaging allows materials to
be recycled and used again. Re-use
of recycled materials helps prevent
environmental pollution and reduces the
demand for raw materials.
EN GLIS H
37
