E N G L ISH
Description (fi g. 1)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
a. Variable speed trigger switch
b. Forward/reverse button
c. Torque adjustment collar
d. Gear shifter
e. Keyless chuck
f. Battery release button
g. Battery pack
h. Worklight
INTENDED USE
This drill/driver is designed for light fastening and
drilling applications.
DO NOT use under wet conditions or in presence
of flammable liquids or gases.
This drill/driver is a professional power tool.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
• This product is not intended for use by
persons (including children) suffering from
diminished physical, sensory or mental
abilities, or for lack of experience and/or for
want of knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone to
play with this product.

Electrical Safety

The electric motor has been designed for one
voltage only. Always check that the battery pack
voltage corresponds to the voltage on the rating
plate. Also make sure that the voltage of your
charger corresponds to that of your mains.
Your FÖRCH charger is double
insulated in accordance with EN 60335;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced
by a specially prepared cord.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the old plug.
• Connect the brown lead to the live terminal in
the plug.
34
• Connect the blue lead to the neutral terminal.
WARNING: No connection is to be
made to the earth terminal.
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3 A.

Using an Extension Cable

An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical Data). The minimum conductor
size is 1 mm ; the maximum length is 30 m.
2
When using a cable reel, always unwind the cable
completely.
ASSEMBLY AND
ADJUSTMENTS
WARNING: Prior to assembly and
adjustment, always remove the battery
pack. Always switch off the tool before
inserting or removing the battery pack.
WARNING: Use only FÖRCH and
D WALT battery packs and chargers.
E
Inserting and Removing the
Battery Pack from the Tool
(fi g. 3)
WARNING: To reduce the risk
of serious personal injury, place
the forward/reverse button in
the lock-off position or turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories.
NOTE: Make sure your battery pack (g) is fully
charged.
TO INSTALL THE BATTERY PACK INTO THE
TOOL HANDLE
1. Align the battery pack with the rails inside the
handle.
2. Slide it firmly into place until you hear the lock
snap into place.
TO REMOVE THE BATTERY PACK FROM THE
TOOL
1. Press the release button (f) and firmly pull the
battery pack out of the tool handle.
2. Insert battery pack into the charger as
described in the charger section of this
manual.
