Cisco Systems Catalyst Express 500 Erste Schritte Seite 12

Run Express Setup
Checklist
Was the SETUP LED
blinking when you pressed
the SETUP button?
Did you connect your PC to
the wrong switch port?
Did you start a browser
session on your PC before
the SETUP LED was solid
green?
Did you start a browser
session on your PC and the
set-up page did not appear?
Did you have a pop-up
blocker running on your PC
when you connected to the
switch port?
Did you have proxy
settings enabled in your
browser software when you
connected to the switch
port?
Did you have a wireless
client running on your PC
when you connected to the
switch port?
Do you need to change the
switch IP address after you
have already completed the
initial setup?
Getting Started Guide for the Catalyst Express 500 Switches
1-6
Recommendation
If no, or you are not sure, restart the switch. Make
sure that the SETUP LED is blinking when you
press the SETUP button.
Verify that you are connected to the switch port
with the blinking LED as shown in Step 6.
If yes, or you are not sure, restart the switch.
Perform Step 2 through Step 6. When the SETUP
LED is solid green, start a browser session on your
PC. Complete the set-up procedure.
If the window does not appear, enter a URL in
your browser, such as cisco.com or another
well-known website.
If yes, disconnect the cable from the switch port,
disable the pop-up blocker, and reconnect to the
switch. Press the SETUP button to continue.
If yes, disconnect the cable from the switch port,
disable the proxy settings, and reconnect to the
switch. Press the SETUP button to continue.
If yes, disconnect the cable from the switch port,
disable the wireless client, and reconnect to the
switch. Press the SETUP button to continue.
Go to the Configure > Express Setup device
manager screen to change the switch IP address.
For more information about changing the switch
IP address, see the User Guide for the Catalyst
Express 500 Switches online at Cisco.com.
Chapter 1 Getting Started Guide
78-17084-03
