Chapter 1 Getting Started Guide
Immediately after you click Submit in Step 9, the Smartports dialog window appears.
Step 10
Click Yes and Submit to accept the predefined port roles. The Smartports window appears.
Here you can change the predefined roles or apply new port roles.
Click No and Submit to apply the Smartports roles yourself. When the device manager
window appears, locate the Contents menu on the left side of the window. Click Configure
and then Smartports.
For more information about the Smartports roles, click Help on the device manager toolbar.
Note: You must upgrade the switch software to change the device manager online help into
one of the available languages. Use the Software Upgrade window to upgrade the switch
software.
When you are finished, disconnect your PC from the switch to end the session.
Step 11
How to Access the Device Manager

Troubleshooting

78-17084-03
The simplest way to configure, manage, and monitor the switch is by using the
device manager. You can access the device manager from anywhere in your
network through a web browser. Follow these steps:
Set up and install the switch in your network, and connect devices as
1.
described in this guide.
Launch a web browser on your PC.
2.
Enter the switch IP address (the address that you assigned in Step 8) in the
3.
web browser, and press Enter. The device manager page appears.
To end the session, close your browser window.
4.
Help with the initial switch configuration is provided below. For additional
assistance, refer to the online documentation at Cisco.com > Technical Support
& Documentation > Switches > Cisco Catalyst Express 500 Series Switches.
Getting Started Guide for the Catalyst Express 500 Switches
Run Express Setup
1-5
