E N
 Dimensions and position of hydraulic components.
 Necessary clearance.
 Power cord position.
 Location of the power supply (electrical socket, at least 3,5 [m] from the edge of the pool).
 Support and its location.
Please remember that water must be conveyed to the product through an appropriate pump.
If the product is used with a filter, the latter must be upstream from the product.
5.6. Connections and start-up.
Empty the pool before installing the product.
See Fig. 10, Fig. 11, Fig. 12.
Switch on the product by inserting the plug into the socket.
The product must be installed and operated by individuals with appropriate training.
The electrical system must meet current international and/or national regulations.
The product must be connected to an power outlet equipped with a residual current device with sensitivity over 30 [mA].
Before starting the product make sure this device is installed in your electrical system. Contact a technician if necessary.
Make sure the product complies with your electrical system.
The power outlet must be at a suitable distance from the water but easily accessible in order to be able to easily turn off the
product in the event of fault (electrical socket, at least 3,5 [m] from the edge of the pool). Cutting the power cord and/or
replacing the power plug is strictly prohibited.
The power cord must be positioned to avoid possible damages such as bends and/or cuts.
5.7. Reinstallation and reuse.
Do not lubricate and/or use detergents and chemical cleaning products.
5.8. Demolition and disposal.
Collecting recyclable material, both those used for packaging (cardboard, nylon, etc.) and those replaced during maintenance is
recommended. Suitable collection of waste material for recycling, processing and environmentally compatible disposal
contributes in avoiding possible negative effects on the environment and health and promotes the reuse and/or recycling of
product materials.
Illicit product disposal by the user may be punishable by current international and/or national laws.
Electric/electronic waste disposal.
5.8.1.
EU directive 2002/96/EC classifies this product as an electrical or electronic tool. The barred bin symbol on the
equipment or packaging indicates that the product must be separated from other waste at the end of its working life.
Therefore, the user must take equipment to electronic and electro-technical waste collection centres at the end of its
working life or return it to the dealer when purchasing similar new equipment, on a one to one basis. Suitable collection
of decommissioned equipment for recycling, processing and environmentally compatible disposal contributes in
avoiding possible negative effects on the environment and health and promote the reuse and/or recycling of device
materials. Illicit product disposal by the user may be punishable by current national laws.

6. Operations and use.

Do not use glue, sealant or other chemical products on threads or other product parts.
To disconnect the product from the power mains, remove the power plug from the power outlet without pulling on the power
cord.
6.1. Operating description.
The product enters the water and illuminates the pool.
6.2. Application range.
The product was designed and constructed to operate in above-ground swimming pool, located outdoors.
Do not use the product in "Spa" pool.
6.3. Use.
Cutting, replacing and/or altering the power cord is strictly prohibited.
The product cannot be used for medical/therapeutic purposes,
6.4. Operating limits and environmental limits.
 Minimum installation depth: 200 [mm]
 Maximum installation depth: 250 [mm]
 Maximum water temperature: +40 [°C].
6.5. Hazards and risks.
Attention to the inlet/outlet points because they can trap parts of the body and/or hair and cause serious personal injuries
and even death (Fig. 5).
Pumps, filters, and other equipment/components of a pool filtration system can operate under pressure. If not correctly
installed they can cause serious personal injuries and even death (Fig. 6).
The product is powered electrically and works in the water, so maximum diligence in its installation and maintenance is required,
in order to avoid danger. Please pay particular attention to: the conditions of its power cord, which must not be damaged.

7. Routine, scheduled and extraordinary maintenance.

Before beginning any work, remember to unplug the electrical plug from the electrical socket.
