Effect Section:
Reloop ELITE offers the possibility to assign an effect section to a channel, so that it can be used independently from the other. This way the
respective left effect section 1 is assigned to deck 1 and the right effect section 2 is assigned to deck 2. This assignment cannot be changed. All
effects are modulated directly in Serato DJ Pro and sent through an effect send/return channel to the mixer. Depending on your active Effect
Packs, a variety of effects will be at your disposal.
It is possible to read the following information on the effect displays:
- Multi effect mode: the three respectively loaded effects for slots 1-3 in abbreviated spelling
- Extended effect mode: the loaded effect in abbreviated spelling
- The selected effect bank's BPM
- Effect beat length
Via the effect buttons FX1-3 the assigned effect slot will be armed, but not activated immediately. If one of these buttons lights up, the effect will
only be activated after FX On or FX HOLD has been activated. By holding one of these buttons while at the same time turning the Beat Length
Encoder, an effect from the available list can be selected. Serato DJ Pro also offers the possibility to carry out individual effect settings and store
these as 2 presets. In order to activate these, press Shift+F1 or Shift+F2, respectively. By pressing Shift+FX3 the current effect bank A selection
will be stored.
The effect's intensity can be adjusted via the Effect Dial. Please consider the settings in the firmware menu FADER SETTINGS.
The Effect Bank's BPM – which usually corresponds to the loaded track's BPM - can be set manually by tapping Shift+FX HOLD. The display will
show the changes. For more precise BPM settings, it is possible to adjust the BPM value in increments of one by pressing Shift and turning the
Beat Length Encoder.
By pressing Shift+FX On, it is possible to switch between the effect bank views "Advanced" and "Multi". Due to the available effect routing architec-
ture, the Serato Sampler's and aux input's audio signals can be contained in the effect loop. The signal can only be assigned to one effect bank.
4.2 Driver Installation
The Reloop ELITE is a class compliant device for Mac OS X, but for Windows a driver is necessary. Please make sure that the driver installation is
complete before using Serato DJ Pro.
Mac
No driver necessary.
Windows
Download the driver via our website: www.reloop.com
Double click the .exe file to begin the installation and follow the instructions on screen. Make sure to re-start the mixer after the installation.
4.3 Connections
Should you prefer turntables for DVS control, connect them to the phono inputs of channels 1 and 2. If you use CD players, please connect them
to the corresponding LINE Inputs.
Put the respective input switches to either USB A or USB B.
In Serato DJ Pro open the settings and go to the AUDIO tab. Depending on the connected devices, please select the corresponding DVS source in
the software:
PHONO: turntables
CDJs: CD players
Custom: depending on the settings in the USB OUT firmware menu, you can also use different DVS sources (PHONO & CDJs)

5. TECHNICAL SPECIFICATIONS

Frequency response: ........................................ 20 Hz - 20 kHz
Inputs: ................................................................. 2x phono RCA
Outputs: .............................................................. Master XLR (balanced)
EQ range at 70 Hz, 1 kHz, 13 kHz: .................. -45 dB (total kill)/ -90/+12 dB
EQ range Mic at 100 Hz, 10 kHz: .................... -26 dB/+12 dB
Dimensions: ........................................................ 290 (w) x 426 (d) x 105 (h) mm (potentiometers: 18.5 mm)
Weight: ................................................................ 6.3 kg
Accessories included: ...................................... Full version of Serato DJ Pro with DVS Expansion Pack, 2x Serato Control Vinyls with NoiseMap
20
2x line RCA
AUX RCA
Mic/line TRS
2x Smart Link USB ports (type A)
2x USB ports (type B)
Master RCA (unbalanced)
Booth TRS (balanced)
Rec RCA (unbalanced)
Headphones 6.3/3.5 mm jack
technology, USB cable, power cord, operating instructions and 90 days BPM Supreme membership
