Technical information
Mounting height
Approx mounting centres
Air volume
Maximum throw
Velocity
Electrical supply
Motor size
Operating current
Starting current
Fuse rating
Thermostatic control
Net weight
Sound pressure level @ 5m
Table 1 Technical information
Notes: Mounting centres based on mounting height. (i.e. the lower the unit, the further
they are apart.) Sound level Q=2,A=160m²
Dimensions
Figure 1 Dimensions and weights
Model
A
DS3-4
492
DS4-4
573
DS6-4
573
DS10-4
694
Table 2 Dimensions and weights
DS3-4
m
4 - 8
m
13 - 16
m³/h
3000
c.f.m
1765
m
8
m/s
3.77
W
108
A
0.52
A
1.5
A
6
kg
15
Lp db (A)
44
B
C
492
332
573
365
573
400
694
440
Reznor, DS-4, Installation Manual, ML 2019-11, D301232 ENGLISH Page No 3
DS4-4
DS6-4
6 - 12
10 - 18
15 - 20
16 - 21
5300
6600
3199
3885
12
18
4.72
6.53
230V 50Hz 1Phase
250
380
1.15
1.75
2.4
6.0
6
Included
19
21
54
57
D
E
332
306
365
345
400
306
440
345
DS10-4
10 - 18
17 - 23
9000
5297
18
5.73
520
2.40
6.7
6
10
27
59
F
Kg
180
13.5
180
17.0
180
17.5
180
25.5
EN
