GreenLinkBox ELT
4.2.1 Changing the standard IP-address
After changing the IP-address you can check if the settings are correct. See page 10.
Change the standard IP-address on the PC
To change the standard IP-address of the GreenLinkBox ELT you have to perform the steps explained in paragraph
"Creating connection settings to connect the GreenLinkBox ELT to the PC" page 4.
Reserve an IP-address that is not yet in use in the current network. This IP-address will be assigned to the
GreenLinkBox ELT as described in the next section.
Change the standard IP-address on the GreenLinkBox ELT
To change the standard IP-address on the GreenLinkBox ELT:
1. Start a web browser on the PC.
2. Enter the IP-address of the GreenLinkBox ELT in the address bar and login using the installer's password.
3. Go to the window System configuration:
4. Change the settings of the Internet Protocol to:
IP address
Subnet mask
5. Click on Send configuration.
The setting will only apply after the GreenLinkBox ELT has been off and on once.
If you want to use loop communication then you have to activate it (default loop communication is off). In the
drop down menu
for the right baudrate. At the bottom op the page the
Reinstate the IP-address of the PC
1. Reinstate the IP-address of the PC (see paragraph "Creating connection settings to connect the GreenLinkBox
ELT to the PC" page 4).
2. Remove the yellow cross cable.
3. Reconnect the PC to the network by using the original network cable.
4. Connect the GreenLinkBox ELT with the normal network cable to a free port in the network.
If you do not want to set the local network for global access you are finished after this step.
The unique reserved IP-address in the previous step.
Same as entered on the PC.
Select second port select Current-Loop. The GreenLinkBox ELT will automatically search
Connecting the GreenLinkBox ELT
Current-Loop status will be displayed.
