Initial Installation For Reception Via Dvb-C/Dvb-T - Caratec Vision CAV220X-DB Bedienungsanleitung

4. Quick Set-Up

4.4. Initial Installation for Reception via DVB-C/DVB-T.

1. DVB-C: Connect the cable connection to the DBV-C input of the television
set.
OR:
DVB-T/T-2 HD: Connect the terrestrial antenna to the DVBT-input of the
television set. If using an active antenna without independent power supply
in the menu switch the „5V antenna power" On (Channel Menu).
2. Turn on the television set with the on/off switch and press the POWER
button on the remote control or on the device.
> The First Time Installation Menu is automatically displayed the first time
you switch on.
3. Sleect the menu Language and Country.
4. Press OK.
> The Tuning Setup Menu is displayed.
5. Select DTV or ATV + DTV as the receiving mode (Tune Type).
58
CAV220X-DB_Anleitung - 20190103.indd 58
First Time Installation
Language <
Country <
Energy Mode <
Auto Tuning
OK
Tuning Setup
Tune Type
<
Digital Type
<
Satellite
<
Scan Mode
<
Channel Type
<
Service Type
Back
MENU
English >
Germany >
Home Mode >
DTV
Satellite >
Astra 19.2E
>
Default >
All Channels >
All
>
Start
OK
07.01.2019 10:58:42
