2. INSTALLING THE XPS 101 SPEAKER SYSTEM

2.1.

Positioning the speaker system

1. Place the satellite speakers on a desk to either side of your monitor, keeping them at least
50cm away from the side walls.
2. Place the speakers at an equal distance from the listener and direct them towards the
listening position.
3. Place the subwoofer directly on the floor. The subwoofer driver is located on the front, and
one passive woofer is located on each side: therefore, be careful not to block the sides of the
subwoofer up against a wall, in order to fully enjoy the best possible bass response.
To determine the ideal placement for your speaker system, try different positions in
succession.
2.2.

Connecting the speaker system to an audio source

Power off the audio source (PC, TV set, DVD player or game console) to which you wish to
connect your speaker system.
- General connection diagram:
4/10 – User Manual
