No. Part Name
1 Upper Sliding Path
2 Reciprocation Rod Assemble
3 Lower Sliding Path
4 Checking Ring
5 Roller Block
6 Small Washer
7 Gear Assemble
8 Impact Balance Block
9 Pendulum Support Patch
10 Needle
11 Right Housing
12 Needle Sleeve
13 Centre Support
14 Screw
15 Washer
16 Bearing
17 Inductor
18 Armature Assemble
19 Carbon Brush Holder Assemble
20 Connection Pipe
21 Screw
22 Stator Assemble
23 Bearing
24 Laser Tip
25 Laser Button
26 Laser Breadboard
27 Protection Steel Wire
28 Reciprocation Rod Fixed Board
29 Pendulum Spring
30 Pendulum Pin
31
Parts List
No. Part Name
32 Anti-dust Clamping plate
33 Anti-dust Block
34 Adjust Speed Block
35 Screw
36 Pendulum Holder Assemble
37 Switch
38 Off Centre Axis
39 Anti-dust Block
40 Clamp
41 Cable Flange
42 Screw
43 Transparent Protection Cover
44 Adjust Knob
45 Checking Ring
46 Left Housing
47 Pendulum Adjust Shaft
48 Steel Ball
49 Spring
50 Pendulum Support
51 Pendulum Holder Roller Wheel
52 Roller Wheel Shift
53 Small Shift
54 Pendulum Holder Spring
55 Cord Sleeve
56 Cable and Plug
57 Inner Hexagon Screw
58 Base
59 Base fi xed Board
60 Base Clamp
61 Inner Hexagon Screw
