EasyGO 2 of US Gebrauchsanweisung Seite 11

NOTE! Before starting to push the pram, make sure that
the brake has been disengaged.
NOTE! Always engage the safety brake, when you leave
the pram on an inclined surface.
NOTE! The brake is not designed for slowing down. It
should be engaged after the pram has been stopped
completely.
NOTE! The pram is not designed for running.
ADJUSTING SUSPENSION STIFFNESS
It is possible to adjust the stiffness of the pram's rear
suspension. The stiffness is adjusted using the lever
under the rear suspension (fig. 14). Repeat for both rear
wheels. The suspension has two settings: stiff and soft.
ATTACHING AND REMOVING THE CARRYCOT
In order to attach the carrycot press it into the pram frame
so that the adapters on both sides of the carrycot lock
onto the catches on the pram frame (fig. 15). They will
lock in place automatically.
ATTENTION! Make sure the carrycot is attached correctly
prior to use.
To remove the carrycot press the buttons on the adapters
at the sides of the carrycot (fig. 16) and pull the carrycot
upwards.
ASSEMBLING AND DISASSEMBLING THE SEAT
The seat should be assembled and disassembled the
same way as for the carrycot (see ATTACHING AND
REMOVING THE CARRYCOT)( fig. 17, 18).
The seat may be assembled with its front and back facing
the movement direction.
NOTE! Before starting to use the pram make sure that the
seat has been assembled correctly.
RESTRAINT SYSTEM
The seat is equipped with a 5-point restraint system (fig.
19). It should be used from the moment a baby starts to
sit by itself. Unfasten the belts, by releasing the forks from
the central buckle, seat the baby, adjust the length of the
belts so that they fit closely to the baby's body, without
oppressing it, and then fasten the forks of all the belts to
the central buckle.
The seat has an additional crotch strap which should be
EN
attached to the safety bar using snaps (fig. 20). This is an
additional element and not be a substitute for using the 5
point safety harness.
NOTE! Always use the restraint system, if the baby can
sit by itself.
SAFETY BAR
To attach the bar, insert its tongues into the slots in
armrests. To remove it, push the buttons located on the
bottom of the slots (fig. 21).
The bar is adjustable. You can detach one of its ends and
move it sideways to place the baby inside the carriage
(fig. 22).
NOTE: The bar is an extra element and you must still use
the five-element harness to secure the child.
ADJUSTING THE LEG REST
The pram is equipped with an adjustable leg rest. To move
it to the right position, press down the buttons on its both
sides.
BACKREST ADJUSTMENT
The seat has an adjustable tilt angle. To make
adjustments, press the buttons on both sides of the seat
and tilt them to the desired position (fig. 23).
RAIN FOIL
The pram is provided with a rain foil equipped with an air
hole at the baby's face height. To assemble it, put one end
under the leg rest or under the carrycot rear, and pull the
other end onto the canopy
(fig. 24). The foil is suitable both for the deep and stroller
version.
FOLDING THE STROLLER
Before folding the stroller, remove the child seat or the
carrycot.
To fold the stroller frame, push the button on the upper
part of the guide on the right side (fig. 25A), then pull up
the levers on both sides of the guide (fig. 25B) and push
them down until total folding
(fig. 26, 27).
11
