Skimmer Connection
1. Push universal adapter into the
suction line in the bottom of
the skimmer.
2. Insert flow regulator into the
universal adapter.
3. Feed any hose section without weights
through the skimmer opening and
attach it to the flow regulator.
Deep Skimmer
45 Elbow
For Australian Skimmer Connections Only
Vacuum plate is not included. Contact an authorized Polaris dealer for more information.
Standard Skimmer
45 Elbow
Vacuum
Plate
Connecting the Hose
1. Set aside the leader hose with hose weight and standard hose with hose weight.
2. Connect remaining hose sections pushing cuffs securely together.
3. Attach standard hose with hose weight to end of hose.
4. Attach leader hose to same end. The leader hose connects to the Polaris.
5. Connect assembled hose to the hose section already attached to the pool.
Flow
Regulator
Universal
Adapter
Shallow Skimmer
90 Elbow
Deep Skimmer
Standard
Hose
Vacuum
Plate
www.polarispool.com
Hose
Suction
Line
On some skimmers it may be
necessary to install an elbow
connector to keep the hose from
kinking. For deep skimmers,
install the 45-degree elbow
between the flow regulator and
the hose. For shallow skimmers,
use the 90-degree elbow.
Shallow Skimmer
90 Elbow
Vacuum
Plate
