the desired position and then turn them over.
2. Next, link them to each other by clicking the male
connector into the female connector (attaching
the long cable to the short cable). Make sure the
positioning lip is in the right place.
3. Then screw the male and female parts together
so that they are also watertight.
4. a. Now click the connectors and cables into the
holes provided in the underside of the base so
that they are tidied away properly.
b. Tip: choose the holes nearest to the next base.
5. Screw the sealing cap onto the male connector
for the last base.
6. Now attach the power supply to the first base.
7. Then turn the bases over and position them
where you want them.
8. Finally, place the rods into the holes provided in
the base(s).
• 1 x power supply - no connection cable =
maximum 9 bases
• 1 x power supply + connection cable 1m =
maximum 8 bases
• 1 x power supply + connection cable 4m =
maximum 6 bases
• 1 x power supply + connection cable 9m =
maximum 4 bases
Extra weight - p12
1. Turn the base upside down and remove its feet.
2. Push all the cables deep into the recesses.
3. Put the extra weight on the bottom of the base,
make sure the holes match up. Push the cables
through the two outer holes, and attach the feet
using the supplied longer screws.
Connection piece - p14
1. Put the two bases against each other and
position the connection piece on top of them as
shown in the drawing. Make sure the holes in the
connection piece match up with the holes in the
bases.
2. Insert a few rods in the bases through the holes
in the connection piece. Insert the other rods
directly in the bases.
Floor fastening - p15
1. Begin by marking the centre of the base and drill
a ø 6 mm holes through the base.
2. Position the base where you want to install your
Sticks. Insert a pen in the hole in the middle of
the base and mark te floor.
3. a. Drill a hole at the marked spot.
b. Insert a plug n° 8 in the hole.
4. Position the base making sure that the hole in
the middle of the base is situated exactly above
the hole. Insert a screw (ø 6 mm, L 80 mm) in this
holes ant tighten it as much as possible.
5. Insert the rods in the base. Tip: If possible, cover
the screw with a black cap. When all the rods are
in place, the cap is not visible.
MAINTENANCE
Fibreglass
CLEANING
Once in a while
The rubber and the fibre glass rods do not require
special maintenance. They can simply be kept dust-
free with a slightly damp cloth.
Rubber
CLEANING
Once in a while
The rubber and the fibre glass rods do not require
special maintenance. They can simply be kept dust-
free with a slightly damp cloth.

USEFUL ADVICE

You do not have to insert all the rods. If you want
more transparency, just use less rods.
To create a special effect, you can mix different colo-
red rods or create smooth colour transitions.
When you disassemble the Sticks space divider,
bundle the rods with the same side up or down, as
the base sometimes leaves marks on the rods.
When re-inserting the rods in the base, make sure
they are facing the same way as they did before the
disassembly.
19
