4

Getting started

4.1

Power supply

For power supply, three AAA Alkaline batteries are required. Before replacing the batteries, turn
off the meter. The battery compartment is located at the rear side of the meter and fixed with two
screws. Loosen the screws, remove the cover, insert the batteries as marked and close the
battery compartment by tightening the screws.
4.2

Preparation

To turn on the meter, press
measuring screen. To turn off the meter, press
socket of the meter. Make sure that the plug is in the right position. The arrow must be visible
from the front side of the meter.
4.3

Options

To change the standard settings, navigate to the submenu "Options". Follow these steps:
5. Press to enter the "Root" menu.
6. Use the
7. Navigate to the desired settings with the
confirm with
8. Select an element with
Setting Element
Measure mode Single
Group mode DIR,
GEN
General 1,
General 2,
General 3,
General 4
Probe mode Auto, FE, N-
FE
Unit settings µm, mils,
mm
until the display reacts. After charging, the meter will show the
key to go to "Options" and confirm with
.
and confirm with
Description
Individual measurements
DIR (Direct):
Data are lost when the meter is turned off. When the
memory is full, the last readings are deleted.
GEN (General 1-4):
The data are saved to one of the 4 groups and are not lost
when turning off the meter. When the memory is full,
measurements are still possible but not saved and "fl" is
displayed.
Auto:
The substrate material is recognised automatically.
FE:
You can measure on magnetic materials only.
N-FE:
You can measure on non-magnetic materials only.
When the meter recognises a magnetic material, it displays
an "F". If the material is non-magnetic, it displays an "N".
Selection of measuring unit
© PCE Instruments
19
. Connect the included probe FN1,5 to the probe
.
keys and
.
