I. Technical Data
UPSI-2406DP1
24 V DC / 3 A
Te c h n i c a l D a t a
Input voltage
Input current
Output voltage
Output current
Capacitive Load
Battery charge current nom.
Charging method
Protection
Interface
Type of battery
Life cycles
Safety / EMC
IP Class
IK Class
Temperature
Max. operation altitude
Derating
(depending on operation altitude)
Humidity
Dimensions (Wx D x H)
Weight (net)
2
UPSI-2406DP1 | UPSI-2406DP2 | UPSI-1208DP2
24 V DC (22.5...32 V)
5 A max.
Normal mode: V
– 0.3 V (Full load)
in
Backup: 23.5 V DC
3 A continuous, 4 A max. (10 s)
3000 µF (24 V Startup)
Depending on load max. 3 A on battery
CC / CV / CP
Deep discharge protection
Overload protection
Overcurrent protection
Reverse polarity protection
USB, RS232, USB-HID
Li-Ion 2.5 Ah / 14.4 V nominal
≥ 500, Charge 0.2 C / Discharge 0.2 C,
60 % of rated capacity @ +25 °C
CE, Class B (EN55032), UL61010 -1, UL61010-2-201
IP20
Not specified
Operating discharge: -20...+60 °C
Operating charge: 0...+55 °C
Storage: -20...+65 °C, recommended 0...+40 °C
5000 m
2000 m operation altitude or higher:
5.7 W / 500 m or reduction of operation temperature
of 3.5 °C / 500 m
Operating: 10...85 % RH, non-condensing
Storage: 10...90 % RH, non-condensing
63 x 100 x 120 mm ±0.5 mm
0.6 kg
