3-BAND EQ Adjusts the low, mid, and high frequencies for each
8
channel.
PFL
Allows the user to listen to a track without having
9
the audience hear.
HPHONE VOL Adjusts the volume of the headphone output
10
CUE MIX Adjusts the headphone mix between
11
tracks and the master output.
RECORD Allows start/stop of software recording feature.
12
MASTER Adjusts the master volume of the unit's output.
13
CROSSFADER Allows you to mix evenly from one channel to another.
14
CH FADER
Adjusts the volume of the individual channel.
15
SYNC Pressing the SYNC button sets the tempo of the
16
track in the corresponding channel to the tempo of
the track in the other channel.
PITCH FADER Adjusts the track's playback pitch/tempo.
17
PITCH BEND Momentarily raises or lowers the track's pitch/tem-
18
po when depressed and returns back to the origi-
nal once released.
SHIFT
Activates secondary functions on the FIRSTMIX PRO.
19
Allows you to set and play hot cues 1, 2 and 3, which
HOT CUES
20
jumps track playback position of the current track.
When SHIFT is active, hot cues 4, 5, 6 are active.
LOOP Engages or disengages the set loop. When SHIFT
21
is active, this sets the LOOP IN point.
RELOOP
Restarts the loop from the beginning point. When
22
SHIFT is active the sets the LOOP OUT point.
AUTOLOOP
Sets programmed bar length beats automatically.
23
Rotating sets different loop lengths. Pushing in acti-
vates the loop. Pushing in again deactivates the loop.
6
FX ON
24
FX SELECT
25
FX AMOUNT
26
MIC VOL
27
the cue
Type of unit........................................................ USB MIDI controller
Power............................................................................... USB-Powered
Connector type................................................................. USB Type B
USB protocol support...................... 1.0, 1.1, and 2.0 (Hi-Speed)
Frequency Response................................ 20Hz-20KHz +/-1.5dB
Total Harmonic Distortion.................................. 0.01% 1KHz/0dB
Signal to Noise Ratio................................................................... 95dB
Dynamic Range.............................................................................. 95dB
Output Level....................................................................... +1dBV RMS
Headphone Impedance......................................................... 32 Ohm
MIC Input Level/Impedance............ 10 mV, 1 KOhm Balanced
Weight............................................................................................,. 4.3 lbs
Dimensions....................................................... 14.6 x 9.1 x 2.4 inches
Visit geminidj.com for more details, updates, and product
Enables/disables the effect.
Toggles between effects. When SHIFT is enabled,
toggles between KEYLOCK and regular pitch mode.
Adjusts the parameter of the effect selected.
Adjusts the level of the microphone signal.
S P E C I F I C AT I O N S
370 x 230 x 61 mm
support
1.95 kg
7
