EN Instructions for use / assembly instructions DE Gebrauchsanleitung / Montageanleitung Talis S 80 72012XX3 Talis S 100 72021XX3 Talis E 80 71702003 Talis E 110 71712XX3...
The product may only be used for bathing, hygienic 67 = Matt Black and body cleaning purposes. Special accessories (order as an extra) The hot and cold supplies must be of equal pressures. seal #98996000 (see page 4) Installation Instructions Cleaning (see page 11) • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or Operation (see page 10) surface damage will be honoured. UngarischTausch • The pipes and the fixture must be installed, flushed and tested as per the applicable standards. • Hansgrohe recommends not to use as drinking water the first half liter of water drawn in the morning or • The plumbing codes applicable in the respective after a prolonged period of non-use. countries must be observed. • After periods of prolonged non-use, but at least • The drain valve must only be used as intended. It is every third day, the fittings must be opened with the not allowed to attach other objects to the drain handle in hot and cold position to prevent stagnation valve, for example a semi-pedestal. in the connecting lines. Let the water run until the • If the instantaneous water heater causes problems or water temperature is constant. if you wish to increase the water flow, the EcoSmart ® (flow limiter) located behind the aerator can be removed.
Seite 3
67 = Mattschwarz Montagehinweise Sonderzubehör • Vor der Montage muss das Produkt auf (nicht im Lieferumfang enthalten) Transportschäden untersucht werden. Nach dem Einbau werden keine Transport- oder Dichtung #98996000 (siehe Seite 4) Oberflächenschäden anerkannt. Reinigung (siehe Seite 11) • Die Leitungen und die Armatur müssen nach den gültigen Normen montiert, gespült und geprüft Bedienung (siehe Seite 10) werden. • Die in den Ländern jeweils gültigen UngarischTausch Installationsrichtlinien sind einzuhalten. • Hansgrohe empfiehlt, morgens oder nach längeren • Das Ablaufventil darf nur zum bestimmungsgemäßen Stagnationszeiten den ersten halben Liter nicht als Gebrauch verwendet werden. Das Befestigen von Trinkwasser zu verwenden. anderen Gegenständen z. B. einer Halbsäule an • Um eine Stagnation in den Anschlussleitungen zu dem Ablaufventil ist nicht zulässig. vermeiden, muss nach längeren Gebrauchspausen, • Bei Problemen mit dem Durchlauferhitzer oder wenn mindestens aber jeden dritten Tag, die Armatur in mehr Wasserdurchsatz gewünscht wird, kann der Griffstellung heiß und kalt geöffnet werden bis eine EcoSmart ® (Durchflussbegrenzer), der hinter dem gleichbleibende Auslauftemperatur erreicht ist. Luftsprudler sitzt, entfernt werden.
Seite 4
98996000 SW 23 mm SW 9 mm (4 Nm) (7 Nm) SW 22 mm SW 22 mm (2 Nm) > 2 min...
Seite 5
60 °C 10 °C 0,3 MPa 36°C 38°C 50°C 60°C 43°C 55°C 17 x...
Seite 6
Talis S 80 Talis S 100 72012XX3 72021XX3 Ø Ø Ø 3 4 Ø 3 4 G 1 / 2 G 1 / 2 Talis E 80 Talis E 110 71702003 71712XX3 Ø Ø Ø 3 4 Ø 3 4 G 1 / 2 G 1 / 2 G 1 / 2...
Seite 7
Talis S 80 72012XX3 Talis S 100 72021XX3 Talis E 80 71702003 Talis E 110 71712XX3 0,50 0,45 EcoSmart 0,40 0,35 0,30 0,25 0,20 0,15 EcoSmart 0,10 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
