pCT1800-50HZ-60HZ
pART No.
10-0001 CAPSTAN DRUM 85 MM
10-0014 ALUMINUM BOX W/COVER AND 4 SCREWS
10-0043 SPACER FOR SAFETY LIP
10-0044 SAFETY LIP FOR CAPSTAN DRUM
10-0057 CABLE PIVOTING ATTACHMENT
10-0067 COUPLING SHAFT FOR ELEC. MOTOR
10-0068 GUARD PLATE PCT1800-60Hz
10-0069 GUARD PLATE PCT1800-50Hz
10-0072 SUPPORT PLATE FOR ELECTRIC BOX
10-0073 ADAPTOR FOR HANDLE PCT1800
10-0086 INPUT PINION
10-0094 WINCH HANDLE
10-0098 BUSHING FOR SAFETY HOOK
10-0101 ROPE ENTRY PULLEY
10-0102 RETAINING WASHER (1/4 X 1-1/4 OD) - ZN
10-0103 ROPE KEEPER
10-0106 ROPE GUIDE FOR CAPSTAN DRUM 85 MM
10-0119 SHOULDER BOLT 5/8 X 1 1/2 - ZN
10-0170 CABLE HOUSING BRACKET
10-0195 LIMIT SWITCH ARM
10-0336 GENERIC INFORMATION AND SERIAL NUMBER PLATE
31-0010 HCS 1/2-13 X 6 - GR5 - ZN
31-0011 HCS 1/4-20 X 2-1/4 - ZN
31-0014 HCS 3/8-16 X 1-1/2 - GR5 - ZN
31-0019 HCS 3/8-24 X 1 GR5 - ZN
31-0020 MACHINE SCREW 10-24 X 1-3/4 - ZN
31-0021 MACHINE SCREW 10-24 X 1/2 - ZN
31-0023 BHCS 1/4-28 X 1/2 - ZN
31-0024 BHCS 1/4-20 X 1 - SS
31-0025 BHCS 1/4-20 X 3/4 - SS
31-0033 SHCS 5/16-18 X 1-3/4 - SS
31-0034 SET SCREW 1/4-20 X 3/8
31-0035 SET SCREW 10-24 X 1/4
PORTABLE WINCH CO. | +1 819 563-2193 | 1-888-388-7855 | www.portablewinch.com
dEsCRipTioN QTY
pART No.
1 32-0002 FLANGE BOLT SERRATED M6-1 x 12 MM - ZN
1 33-0004 K-LOK LOCKNUT 10-24 - ZN
33-0005 NUT 1/2-13 NYLON - ZN
1
35-0004 FLAT WASHER 1/2 - ZN
1
1 35-0006 FLAT WASHER 1/4 - ZN
1 35-0013 FLAT WASHER 3/8 - ZN
1 35-0017 LOCK WASHER 3/8 - ZN
39-0028 TAPPING SCREW - TYPE B-#10x1/2
1
41-0004 CABLE END
1
1 41-0018 THROTTLE CABLE ASSY PCT1800
1 42-0006 ELECTRIC CORD 14 AWG 3/C 300V
ELECTRIC CORD CONNECTOR 1/2-WATERPROOF
1 42-0007
42-0008 PLUG 15A-125V-2 POLES-3 PRONG SPLASHPROOF & DUST-TIGHT
2
42-0010 DUSTTIGHT GRIPS
1
1 42-0015 CONTACTOR 2 POLES 120 VOLTS 40 AMP. 50/60Hz
1 42-0016 ON/OFF LIMIT SWITCH
1 42-0019 PLUG CEE 7/7 - 250V - 16 AMP GROUNDED
42-0020 CONTACTOR 2 POLES 230 VOLTS 40 AMP. 50/60Hz
1
42-0021 ELEC. MOTOR VL3506-3/4HP-115VAC-60Hz-1PH-TEFC-3450 RPM
1
1 42-0022 ELEC. MOTOR VL3506-3/4HP-230VAC-50Hz-1PH-TEFC-3450 RPM
1 43-0000 KEY FOR COUPLING SHAFT (3/16 X 3/16 X 7/8)
1 43-0005 KEY FOR INPUT PINION (3/16 X 1/8 X 3/4)
43-0013 KEY FOR CAPSTAN DRUMS 57 MM, 76 MM, 85 MM & 108 MM
1
44-0019 VINYL GRIP
4
2 44-0022 LABEL - ROPE DANGER
2 44-0026 LABEL - ROPE INSTALLATION
44-0034 LABEL - SPECS SPEED VS DRUM DIAMETER
3
70-0007 RGS - ATTACHMENT ASSY.
1
70-0008 RGS - PIVOTING ASSY.
2
2 PCA-1281 SAFETY HOOK WLL: 3/4 TON
1 PCA-1110 OPTIONAL 57 MM CAPSTAN DRUM, ROPE GUIDE AND SCREWS
10-0096 CAPSTAN DRUM 57 MM
2
10-0100 ROPE GUIDE FOR CAPSTAN DRUM 57 MM
1
31-0025 BHCS 1/4-20 X 3/4 SS
PORTABLE WINCH CO. | DEALER'S GUIDE
ExplodEd viEws
dEsCRipTioN QTY
4
2
1
4
1
1
4
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
