Neurotech MediTens XP Gebrauchsanweisung Seite 9

English
MediTens XP display (Fig. 3)
MediTens XP has a unique display, which gives the user a precise overview of the battery
status, the completed treatment time, contraction/ relaxation phases and program selection.
1. The Lock button is activated and prevents unwanted changes to the intensity level.
2. Load Sense Feature: this appears when a poor connection between a lead and its
electrode or between an electrode and the skin is detected.
3. During treatment the intensity bars will rise and fall corresponding to the contraction/
relaxation cycle on each channel.
4. Displays the length of time left/ elapsed in the current session in hours, minutes and seconds. For a set treatment
time program, the timer will count down in minutes and seconds. For an open treatment time it will count up from zero
in minutes and hours.
5. Battery status indicator, indicates battery power remaining.
6. The clock icon appears when the total treatment time is displayed and when the clock is counting upwards.
7. Indicates which treatment program you are running (1 to 5).
8. Trigger mode enabled. (Programs 1, 4 and 5)
Burst mode enabled. (Programs 2 and 3)
9. The pause indicator appears when the treatment has been paused.
Fig. 3
1.
2.
3.
9.
4.
5.
6.
7.
8.
9
