Guidelines when installing sensors
Dos and Don'ts on where to install the sensor.
Figure 2:
No obstructions (consider seasonal changes). Avoid strong
light. Avoid splashing the unit. Avoid unstable ground.
Figure 3: Indoor and outdoor protection distances between
transmitter and receiver.
Model Outdoor (m)
PB501 20
PB511 40
PB521 60
Avoid overhead wiring.
When installing indoors, use similar procedures as for
telephones/intercoms. Outdoor wiring should be in PVC if used
below ground or use a burial cable. Use conduit for above-
ground wiring.
Figure 4: Recommended installation height.
Figure 5: Adjust the lens vertically (1) and horizontally (2) so
that the unit can work in all directions. See examples A-C.
Figure 8: Calculating beam expansion (A). (B= protection
distance)
A=0.03 x B
Model B (m)
PB501 20
PB511 40
PB521 60

Wiring the system

Figure 6: Terminal configuration.
Figure 7: Examples of connections.
Figure 9: Wiring distance for a power supply (m).
Note: The maximum wiring distance when two or more sets
are connected is the value shown divided by the number of
sets.
Note: The signal line can be wired up to approximately 1000 m
with AWG22 (diameter 0.65 mm) telephone wire.

Installing the system

Installing a wall-mounted unit (figure 12)
Remove the cover from the unit (1) and detach the mounting
plate (2). Break the grommet on the mounting plate and pull
the wire thorough (3) (plug the opening between the grommet
and the wire with a sealing material.) Secure the plate with
screws. Pull the wire through the sensor body (4) and attach to
the sensor plate.
Once the wiring is completed, adjust the alignment, check the
operation and re-attach the cover. It is not necessary to seal
the unit as it is waterproof.
If surface-wired (5), break the knockouts on the rear of the unit:
P/N 1077838 • REV D • ISS 19MAR19
Indoor (m)
40
80
120
A (m)
0.6
1.2
1.8
A= wiring from the top; B= wiring from the bottom; C=
knockouts. Pull the wire through as shown and attach it to the
mounting plate.
Installing a pole-mounted system with the PB50-PA pole
attachment (figure 10)
Insert two oval countersunk head screws (M4x20) in a pole
bracket (1). Fix the pole mounting plate to the pole with the
bracket. Remove the cover from the unit and detach the
mounting plate. Insert two M4x10 screws in the pole-mounting
plate (2) and fix the sensor mounting plate to them. Continue
as explained for wall-mounted units.
Installing a back-to-back pole-mounted system & right-
angle pole mounted system (figure 11)
Fix the pole-mounting plate for the first PB50-PA unit. Position
the pole bracket of the second PB50-PA unit underneath the
first pole-mounting bracket and fix the second pole-mounting
plate upside down. Continue as explained for wall-mounted
units.
Aligning and operating the unit
See figure 13.
Figure 13 description
1 Vertical adjustment screw. Clockwise: upwards. Counter-
clockwise: downwards
2 Horizontal adjustment
3 View finder
Supply power to the unit with the cover removed. Set the same
beam channel for both the transmitter and receiver (factory
default is channel 1). To align the transmitter lens to the
receiver lens, position the viewfinder between the two lenses
and look through it. Line-up the optics horizontally and
vertically until the opposite unit is visible.
Figure 14: Fine tuning the alignment.
Figure 14 description
1 Tester 3-10 VDC
2 Attenuation sheet
3 Alarm LED
4 Attenuation LED
Continue fine tuning the unit until the receiver attenuation LED
turns OFF.
If the unit is used outdoors, place an attenuation sheet over the
receiver optics and continue fine tuning until the receiver LED
turns OFF. It is recommended to use a tester when doing
adjustments. Confirm the beam level by inserting the tester in
the monitor jack of the receiver. See the table below for
monitor output voltage (1) by recommended beam level for
outdoor (2) and indoor (3) usage. Low readings need to be
readjusted (4).
Monitor output Alignment outdoor (2) Alignment indoor (3)
voltage (1)
more than 700 mV Best
250-700 mV Good
Best
