DIP switch

The DIP switch provides the functionality described in Table 1
below.
Table 1: DIP switch description
No. Name Function
1. HL Modem update
2. TEST Factory test mode
3. BOOT Firmware update mode
4. Reserved
LEDs
In the following LED descriptions, a flash is defined as 250 ms
on and 250 ms off. Groups of flashes are separated by 1 s off.
MI_ST
The MI_ST LED (green) displays the status of the
communication interface to the panel.
Table 2: MI_ST LED status
Rate (±10%)
Duty cycle Description
—
100%
Power on (in case none of the cases
below are valid)
—
0% No power or power failure
25% 1 s Initialization OK, waiting for
communication
50% 1 s Everything OK, communication running
75% 500 ms Hardware failure
50% 250 ms Failure in communication, waiting for
reinitialization
CALL
The CALL LED (red) indicates status of the audio information
transmitted to the central station.
Table 3: CALL LED status
Rate (±10%)
Duty cycle
—
100%
—
0%
10% 1 s
50% 1 s
RSSI
The RSSI LED (green) indicates the field strength or signal
strength found by the GSM module. The number of flashes
indicates the level.
Table 4: RSSI LED status
Flashes Description
Off No field strength (no network detected)
1 to 4 Field strength indication from poor (1) to excellent (4)
4 / 44
Default value
Off
Off
Off
Off
Description
Connected
Offline
Connecting
Ringing present
NET
The NET LED (green) indicates the status of the network. The
meaning of the number of flashes is described in Table 5
below.
Table 5: NET LED status
Flashes Description
Off Not registered
On Registered to home network
1 Registered to roaming network
2 Searching network
3 Denied
4 Unknown
PSUE
The PSUE LED (red) indicates the status of the power supply.
Table 6: PSUE LED status
State Description
Off Power supply okay
On Power supply problem
GPRS
The GPRS LED (yellow) indicates the status of the GPRS
communication.
Table 7: GPRS LED status
State Description
Off GPRS is not available
On GPRS is available, connection established
Blink GPRS is available, connection established, sending data
Flash GPRS is available, connection not established
SIME
The SIME LED (red) indicates the status of the SIM card. The
meaning of the number of flashes is indicated in Table 8 below.
Table 8: SIME LED status
Flashes Description
Off Ready
1 PIN error
2 PUK error
3 PIN 2 error
4 PUK 2 error
5 SIM blocked from network
On SIM not present
Alarm transmission requirements
All GSM module faults are logged in the control panel and
indicated by the fault LED and corresponding fault messages
on the keypad display.
