CONNECTION AND OPERATION
A playback device can be connected via the balanced XLR inputs. The integrated Bluetooth module enables wireless control via smartphone or tab-
let. There is also a stereo link function for wireless transmission of the Bluetooth signal to another MAUI 44 G2 PA system as a stereo extension. Both
the volume of the entire system as well as the volume of subwoofer relative to the overall volume can be adjusted on the device. An optionally
available subwoofer extension can be used in two different setups together with the MAUI 44 G2 PA system.

CONNECTIONS, OPERATING AND DISPLAY ELEMENTS

1
IN
1
Balanced line stereo input with two 3-pin female XLR sockets for connection of a playback device (e.g. mixer). Any stereo signal present is internally
summed to mono.
MAIN
2
Level control for overall volume. The subwoofer volume level is controlled by adjusting the SUB level control accordingly. When the subwoofer is
used as subwoofer extension, the level control is disabled and the MAIN display field is turned off.
SUB
3
Setting the volume balance between the subwoofer and the column speaker. When the subwoofer is used as subwoofer extension, the level control
is deactivated and the SUB display field is turned off.
6
2
4
8
7
3
9
5 6
