Akasa INTEGRAL FUSION Handbuch Seite 4

Using Integral Fusion
1
A C
B
E1 E2
A
Backup button: press to invoke the backup software
Function Light:
B
Access: show the harddisk data access activity
C
Power: show the power is switched on
D
Memory card: show the memory card data access activity
Memory card slot:
E1
Compact Flash I / II
E3
Smart Media
2
E
D
A
power adaptor connector
B
power switch
C
USB port
D
USB hub
E
Fan control dial: change the speed of the fan at the
bottom of the enclosure shown as below
fusion
D
E3 E4
E2
MMC / SD
E4
MS / MS Pro
C A
B
3
Fit the dc power adapter plug into the enclosure.
4
Plug one end of the USB lead into the PC port that you
wish to use and the other end plug into the enclosure.
