your child sitting in it.
STROLLER SAFETY HARNESS
7. This stroller has a five-point safety harness featuring two
shoulder straps, two adjustment buckles, a waist strap and a
crotch strap with buckle.
WARNING: To use it with children from birth to approx. 6
months of age, you must use the shoulder straps, first thread-
ing them through two adjusting holes (Fig. 7).
fasten the straps by passing the waist clip (A) through the
buckle on the shoulder strap (B), and secure in the crotch strap
buckle (C) (Fig. 7A). Adjust the height of the shoulder straps so
that they correctly fit your child's shoulders. Always make sure
that the straps are fastened correctly. To unfasten the waist
strap, press the central button and pull the side clips.
WARNING: After removal of the safety harness (e.g. for wash-
ing), ensure that the harness is reassembled correctly using
the anchorage points. The harness must be re adjusted.
ADJUSTING THE BACKREST
8. To adjust the backbrest using the rear adjustment system,
pull the lever and push the backrest into the desired posi-
tion. To adjust the backrest, act on the rear adjustment sys-
tem by pulling up the lever and pushing the backrest back
(Fig. 8). To revert the backrest to the original position, follow
the same steps but push the backrest forward.
WARNING: The child's weight can make these operations
more difficult.
REAR BRAKES
The rear wheels have linked brakes, which can be applied si-
multaneously on both rear wheels using one pedal only.
9. To apply the break, press the pedal next to the rear wheels
downwards (Fig. 9). To release the braking system, push the
pedal upwards (Fig. 9A).
SWIVEL WHEELS
10. To let the front wheels swivel, lift the lever found above
the front wheels (Fig. 10). Use the swivel wheels on smooth
surfaces. To lock the wheels, lower the lever.
WARNING: The swivel wheels make the stroller easier to han-
dle; it is however recommended to use the wheels locked on
uneven ground to guarantee better stability (on gravel, un-
paved roads etc.).
WARNING: Both wheels must always be locked or unlocked
at the same time.
ADJUSTABLE LEGREST
The legrest can be adjusted to 2 positions.
11. To lower the legrest, pull the tube towards you and rotate it
downwards (Fig. 11 – 11A). To raise it, pull the tube towards
you and push the legrest upwards.
HANDLE ADJUSTMENT
12. The handle can be adjusted to 3 positions by pressing the
buttons at its base (Fig. 12).
CLOSING THE STROLLER
WARNING: When opening the stroller, ensure that your child and
any other children are at a safe distance. Make sure that during
these operations the moving parts of the stroller do not come
into contact with your child. Before closing the stroller, make sure
that the storage basket is empty and the canopy is closed.
The stroller has a closing device that can be used with one
hand.
13. The stroller closing control is located under the seat cush-
ion. To close the stroller, raise the seat cushion, slide the
locking device and then lift the handle (Fig. 13). The stroll-
er will fold on itself (Fig. 13A). We recommend leaving the
front wheels free while closing the stroller to achieve max-
imum compactness.
REMOVING SEAT LINING
To remove the hood and bumper bar, refer to the "OPENING
AND FIRST ASSEMBLY" paragraph and repeat the steps in re-
verse order.
14. Open the safety harness and remove the waist straps and
crotch strap from the dedicated holes (Fig. 14-14A).
15. Detach the fabric on both sides of the stroller, removing it
from the plastic pins (Fig. 15) positioned under the handle.
16. Release the fabric from the plastic pins positioned under
the seat (Fig. 16).
17. Remove the fabric from the legrest (Fig. 17) then remove it
from the backrest (Fig. 17A), paying attention to the back-
rest adjustment lever.
To fit the lining on the stroller again, repeat the steps illustrated
above in reverse order.
BASKET
If the basket is removed, follow the steps below for assembly.
18. Place the fabric flap on the rear tube and close the velcro
fastener (Fig. 18).
19. Secure the strap at the base of the rear legs and close it
with the velcro fastener (Fig. 19). Repeat this operation on
the other side as well.
20. Fasten the back of the basket to the plastic pins positioned
on the rear legs (Fig. 20).
21. Fasten the sides of the basket to the same plastic pins, on top
of the fabric section attached previously (Fig. 21).
22. Complete fastening by passing the front straps through
the hole and secure using the snap buttons (Fig 22).
USING THE CAR SEAT ON THE STROLLER
On the Chicco Multiride stroller it is possible to fit the following
elements, which can be purchased separately:
• Kaily car seat
• Kiros i-size car seat with Fast In fastening
All car seats for use on the stroller require the special adaptors
sold separately.
WARNING: FOR THE ASSEMBLY AND/OR USE OF THE ITEMS
LISTED ABOVE, REFER TO THE RELEVANT MANUALS.
WARNING: Before using the stroller with the car seat, always
make sure that the fastening system is properly locked.
When fastened to the stroller, the car seats listed above can be
used for children from birth up to 13 kg in weight or until they
are able to sit independently.
To install the car seat, with the stroller open, fold the sun canopy,
recline the backrest completely and remove the bumper bar.
WARNING: Never install the child car seat in the forward fac-
ing position.
ACCESSORIES
LEG COVER
23. The legrest must be inserted in the lower part in order to
