Led Indications; Technical Data - GE ATS1151 Bedienungsanleitung

L ( 5)
INKS FIG
TERM Fitted if this device is the last device on the
system databus. For more details see the
ATS control panel installation guide.
LED
INDICATIONS
Fig. 9 LED position and colour
L1 Dual-colour LED red or
green
This LED stays off when
no areas are assigned
to its alarm group.
Yellow LED
L2
L3 Red LED

Technical Data

Supply Voltage
Current consumption
Dimensions in mm (H x W x D) (ATS1156)
Dimensions in mm (H x W x D) (ATS1151)
Operating temperature
Humidity Non condensing
Weight (ATS1156)
Weight (ATS1151)
Function
Green when an area is disarmed
(area assigned to the RAS alarm group).
Red when an area is armed
(area assigned to the RAS alarm group).
Yellow is the "ready" LED. When the
area is ready to be secured, the yellow
LED switches on.
Red and flashing when an alarm occurs
in any of the areas assigned to the RAS
2
12V
12V 45 mA
96 x 96 x 40
96 x 67 x 28
-25°C to +70°C
93%
458 g
226 g
Extra Comments
If area is disarmed and the door
is opened, it will flash green for
the access time.
If area is armed, and the door
is opened, it will flash red for
the access time
All the inputs in the area assigned
to the RAS alarm group should
be sealed.
