DMX-RDM
This unit supports the DMX protocol extension RDM. RDM (Remote Device Management) is a new, open and bi-
directional protocol standard for DMX-512 controlled units. The protocol allows to receive status information about a
unit or to change configurations on a unit. Prerequisite for this function being an RDM compatible controller. E.g. Oase
WECS 1024.
How does RDM work?
The permanently transmitted DMX data flow briefly pauses (several milli-seconds), and an RDM data package (mes-
sage) is sent directly to a subscriber. The subscriber evaluates the information in the data package and sends an
answer (semi-duplex) on the same line. Targeted polling to a subscriber via its UID (Unique ID) prevents several
subscribers from answering simultaneously.
RDM parameter overview:
General parameters
COMMS_STATUS
STATUS_MESSAGES
STATUS_ID_DESCRIPTION
SUPPORTED_PARAMETERS
PARAMETER_DESCRIPTION
DEVICE_INFO
PRODUCT_DETAIL_ID_LIST
DEVICE_MODEL_DESCRIPTION
MANUFACTURER_LABEL
DEVICE_LABEL
SOFTWARE_VERSION_LABEL
DMX_PERSONALITY
DMX_START_ADDRESS
SENSOR_DEFINITION
SENSOR_VALUE
RECORD_SENSORS
IDENTIFY_DEVICE
RESET_DEVICE
Specific parameters
Curve X1
Curve Y1
Curve X2
Curve Y2
Curve X3
Curve Y3
Error monitoring
Runtime hours
Startup counter
Control mode
Config mode
Maintenance and cleaning
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures:
− Prior to reaching into the water, disconnect the power supply to all units used in the water.
− Disconnect the power plug prior to carrying out work on the unit.
If necessary, clean the unit with clear water using a soft brush.
− Never use aggressive cleaning agents or chemical solutions. These could attack the housing surface or impair the
function.
− In the event of stubborn furring (calcium deposits), a common household cleaner free from vinegar and chlorine can
be used. Subsequently, clean the pump thoroughly using clear water.
GET
SET
Description
CMD
CMD
*
*
Shows general status information of the bus interface
*
Used to manage status messages
*
*
RDM parameter overview
*
Description of all parameters
*
Brief overview of the most important features
*
Additional feature
*
Type designation
*
Manufacturer name
*
*
Labelling field
*
Version number of the firmware
*
*
Operating behaviour (currently the setting cannot be changed)
*
*
Reading and setting the DMX start address
*
Sensor information
*
*
Sensor value
Sensor 1 = „TempErrCount", temperature error counter
Sensor 2 = „MotorFailureCount" motor failure counter
Sensor 3 = „ActualSpeed", current actual speed
Sensor 4 = „NominalSpeed", current setpoint speed
Sensor 5 = „PWM", current PWM value
Sensor 6 = „Temp", current operating temperature
*
Buffering the sensor value
*
*
0 = Normal operation,
1 = Pump will switch on and off again in short intervals. This function is helpful to
identify the unit in the field.
*
Executes a reset.
1 = Warm start / 255 = Cold start
GET
SET
Description
CMD
CMD
*
Support value 1 of the stored pump characteristic curve
*
*
Support value 2 of the stored pump characteristic curve
*
*
Support value 3 of the stored pump characteristic curve
*
*
Only for service purposes
*
Operating hour counter for the running period
*
Startup counter
*
Only for service purposes
*
Only for service purposes
- GB -
