Remote Installation
Step 6 Serial Settings
The SMB Remote IP Device supports one serial device, which can be attached
using the included serial cable. The serial device can be accessed remotely via
the IP Device's VT100 serial terminal emulation.
If you have a serial device connected to the Switch, such as a power distribution
unit (PDU), you must configure the serial (RS232) settings. To open the
Serial-Settings page, click "Serial Settings" under "Administration" in the far-left
menu (see Fig. 5).
To configure your serial device:
1.
Type in the name of the serial device.
2.
Using the drop-down menus, select the correct baud rate, parity, and
data-and stop-bit parameters for the device.
3.
Check the "Show" box. This will make the serial device appear in the list
of servers and devices that can be accessed through the quick-access
toolbar.
UK-25
Fig. 5 Serial-Settings Page
