Dimensions
Top View
26.75"
19.35"
(491 mm)
1.75"
16.25"
(44 mm)
(413 mm)
22.25"
(565 mm)
5.25"
(133 mm)
Side Views
CPU Holder
10"
(254 mm)
5.5"
(140 mm)
0.5"
5"
(13 mm)
(127 mm)
Front View
2 of 22
9.5"
(241 mm)
38.15"
(969 mm)
28.65"
(728 mm)
11.4"
(679 mm)
(290 mm)
5"
(127 mm)
6.6"
(168 mm)
2x 0.28"
(7 mm)
Wall Mount Bracket
Side View
(61 mm)
4.37"
(111 mm)
Front View
(35.1 mm)
Cable Channel
Top View
1.9"
(49 mm) 4.4
Ø
15.16"
(385 mm)
10.8"
(275 mm)
12.28"
(312 mm)
Mouse/Scanner Holder
2" - 8"
(102 - 203 mm)
3.5"
(89 mm)
Side View
Wall Track
1"
2.38"
8"
Ø 0.42"
(10.7 mm)
2.5"
8"
(63.5 mm)
1.38"
8"
1.1"
(27 mm)
0.6"
(14 mm)
8"
mm
1"
11.3"
(288 mm)
11.6"
(294 mm)
Front View
Top View
4"
2"
1/2"
5"
0.850"
Top View
3"
(76 mm)
3.2"
(81 mm)
1.75"
(44 mm)
888-45-166-W-00rev.B • 03/09
