Choose Run Mode
MENU
RUN MODE
PERSON
The operating mode is set in menu RUN MODE. For operation on a DMX-controller DMX needs to be
set. SLAVE sets the fixture into slave mode.
Edit User Programs
MENU
PERSON MANUAL
In the menu MANUAL, submenu EDIT the user programs PROGRAM.01 to PROGRAM.10 can be
edited.
Every program can have up to 30 steps (scenes). Every step persists of the parameter colours
RGBAL, ZOOM, FOCUS, GOBO SPEED, STROBE „0-25Hz", TIME and FADE. User programs can
be transfered to other fixtures (see master/slave)
Step-by-step programming of the custom stand-alone programs with up to 30 different steps.
NOTE: For less than 30 steps the TIME and FADE of the last step needs to be set to 0.
Example for time settings of a stand-alone programm with 3 steps:
HSIC DMX
HSIC SLAVE
PROGRAM.01
HSIC EDIT
PROGRAM.02
o
o
o
PROGRAM.10
Step 1 TIME = 4 FADE = 3
Step 2 TIME = 5 FADE = 2
Step 3 TIME = 0 FADE = 0
SCENE-01 RED
SCENE-02 GREEN
o
BLUE
o
AMBER
o
SCENE-30 LIME
ZOOM
FOCUS
GOBO SPEED
STROBE
TIME
FADE
USE = YES
USE = YES
USE = YES
