8. MAINTENANCE / SPECIFICATION

9. CE DECLARATION OF CONFORMITY

Turn the battery around until it can be inserted into the slot.
Reason for different battery pack working times. Charging time issues, as above,
and having not used a battery pack for a prolonged time will reduce the working life
of the battery pack. This can be corrected after several charge and discharge opera-
tions by charging & working with your drill. Heavy working conditions such as large
screw into yard wood will use up the battery pack energy faster than lighter working
conditions. В not re-charge your battery pack below 0ºC and above 50ºC as this will
affect performance.
Hot battery pack protection. The normal charging temperature is between 0ºC
and 50ºC. When the battery pack is too hot, it automatically starts a HOT battery
pack delay, and suspends charging until it has reached the correct temperature.
The charging process will then automatically begin.

MAINTENANCE

Your tool requires no additional lubrications or maintenance. There are no user
serviceable parts in your tool, battery pack or charger. Never use water or chemical
cleaners to clean your tool. Wipe clean with a dry cloth. Always store your tool in a
dry place. Keep the motor ventilation slots clean. Occasionally you may see sparks
trough the ventilation slots. This is normal and will not damage your power tool.

SPECIFICATIONS

Rated voltage (peak) 20 V
Charger voltage 230-240V - 50Hz
No load speed 0-400/0-1400/min
Number of clutch positions 25 + 1
ACCESSORIES: CTR20Li - 2 Ah Li-Ion battery pack - 1, 1 hr. charger
CTR20-2Li - 2Ah Li-Ion battery pack - 2, 1 hr. charger
Not all the accessories illustrated or described are included in standard delivery.
NOISE/VIBRATION Measured in accordance with EN 60745 the sound pressure
level of this tool is L = 97 dB(A) and the sound power level L
wA
Standard deviation: K = 3 dB.
a
The vibration - = 4,56 m/s² (hand-arm method; uncertainty K =1.5 m/s²)
hD
CE DECLARATION OF CONFORMITY
We STATUS ITALIA S.R.L. as the responsible manufacturer declare that the
following STATUS machine(s): Cordless Drill/Driver CTR20Li / CTR20-2Li are of
series production and сonforms to the following European Directives: 2006/42/EC
And are manufactured in accordance with the following standards or standardised
documents: EN60745-1:2009+A11:2010, EN60745-2-1:2010, EN60745-2-2:2010,
AfPS GS 2014:01PAK
The technical documentation kept by the manufacturer: STATUS ITALIA S.R.L.,
via Aldo Moro, 14/A, 36060 - Pianezze (VI), ITALY
Torque (hard/soft) 50/35 N.m
Max. chuck capacity 13 mm
Battery capacity 2 Ah Li-Ion
Charging time 1 hr
= 86 dB(A),
pA
Caron Giacinto
Director
STATUS ITALIA S.R.L.
10 11
