Type
MBT 9110

Electrical specifications:

Specifications range:
-40°C to +85°C
Common specifications:
Supply voltage, DC
Galvanic isolation,
Galvanic isolation, EEx, MBT 9110, 084Z7443 .. 7,2...30 VDC
Internal consumption ................................................ 25 mW...0.8 W
Voltage drop ................................................................. 7.2 VDC
Isolation voltage, test / operation ......................... 1.5 kVAC / 50 VAC
Warm-up time .............................................................. 5 min.
Communications interface ...................................... Loop Link
Signal / noise ratio ...................................................... Min. 60 dB
Response time (programmable) ............................ 1...60 s
EEprom error check .................................................... < 3.5 s
Signal dynamics, input .............................................. 20 bit
Signal dynamics, output ........................................... 16 bit
Calibration temperature ........................................... 20...28°C
Accuracy, the greater of general and basic values:
Input type
All
IC.PS.P40.B2.52/520B2754
Version
Galvanic isolation
Galvanic isolation, EEx
MBT 9110, 084Z7442 .. 7,2...35 V
General values
Absolute
accuracy
≤ ±0.05% of span
084Z7442
084Z7443
Temperature
coefficient
≤ ±0.01% of span / °C
