Safety advices:
Installation and repairs to the equipment may only be carried out by
technicians observing the current VDE guidelines. No liability will be
assumed in the case of faulty installation and commissioning.
The applicable national safety regulations and current standards such as
DIN EN 60728-11 must be observed.
Do not open the device. Opening the device or removing its covers
causes risks, for example due to high voltage.
Under no circumstances may the antenna be installed under or in close
proximity to overhead power lines! A minimum lateral distance of >1 m
from any electrical equipment must be observed. Touching electrical
installations may cause death!
Never work on antennas during thunderstorms or when a thunderstorm
is approaching. There is a risk of death!
Never install antennas on buildings with inflammable roof coverings
such as in thatched roofs! In such cases there is a fire hazard due to
atmospheric surge voltages (static electricity) or lightning (e.g. during
thunderstorms).
Choose the location of installation or mounting so that the power plug
can be reached and pulled out of the socket easily in case of danger.
Choose the location of installation or mounting such that children may
not play unsupervised near the equipment and its connections.
Choose the location of installation or mounting of the plug-in power
supply so that under no circumstances liquids or objects can get into the
power supply (e.g. condensation, water coming from leaking roofs or
flowing water, etc.).
Use only the plug-in power supply unit included in the delivery scope! By
no means is it allowed to replace any parts of the power supply unit or
to make modifications. Otherwise, there is a risk of mortal injury!.
Power feeding cables as well as feeder lines may not be damaged or
clamped by objects of any kind.
Avoid exposure of the power supply to heat sources (e. g. radiators.
other electrical devices, chimney, etc.). Power supplies that are equipped
with ventilation slots must under no circum-stances be covered or
blocked. Also ensure for a generous air circulation around the power
supply. Absolutely avoid that cables come near any source of heat (e.g.
radioators, other electrical devices, chimney, etc.).
State of the art 2019-10-04
Technical improvements, changes in design, printing- and other errors expected.
Technical data:
Typ
Frequency range
Gain TERR
Noise figure
Output connector
Remote power supply
Current consumption
Operation temperature range
Dimensions (W × H × D) appr.
Protection class
RED compliance
Plug-in power supply
Herewith AXING AG declares that the marked products comply with the valid
guidelines. You can call up the complete EU declaration of conformity for
download by entering the article in the search field at www.axing.com.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Manufacturer
EEA contact address
AXING AG
Bechler GmbH
Gewerbehaus Moskau
Am Rebberg 44
8262 Ramsen
78239 Rielasingen
TAA 3-20
85...774 MHz
22 dB
TAA 3-20
≤ 5,5 dB
F
premium-line
5...12 V=
<50 mA
DVB-T/T2 | FM | DAB+
-20...+65°C
370 x 260 x 49 mm
antenna with LTE filter
IP 35
Class 3
(class 3)
230 V~ 50 Hz/3W | 12V=/0,2A
Operation instructions
