Dimensions
• Box 90x90X115 mm included terminal blocks.
• Front panel 96X96 mm.
• Weight 0,4 Kg.
Power Supply
• Power supply (24÷240) Volt AC/DC ± 10% 50/60 Hz without polarity
respect, absorption 4 VA.
Inputs
• Four analogical inputs, temperature control and mapping with PT100
sensor at three wires inside range from -10 °C to +200 °C.
Outputs
• 4 relays 250 VAC, 5 A max (resistive load), free switch contact.
Characteristics
• Self-extinguishable NORYL Box.
• Display with light segments.
• Visualisation of max temperature and the relevant channel in the
automatic mode.
• Alerts of pre-alarm, alarm, probes fault, fanning, manual function, historic
highs.
• System programming directly by frontal panel.
• Possibility to select independently each channel.
• Limit of alarm and pre-alarm settable in the range (-9 °C ÷ 199 °C).
• Precision ± 1% on full scale ± 1 digit.
• Cooling fan control on three or four channels.
• Comparison of temperature for cooling fan between two different levels
(L and H).
• Four selectable operating modes.
• Detection of fault probes, maximum flexibility of managing and semplicity
of programming, checking of validity of the insert data during programming
phase.
• Continuos storage of planned and reached values by each channel (limits
and historic highs).
• Dielectric isolation: 2.5 Kv for 60".
• Software configuration to control the environment temperature.
