Using The Remote Control - Concept OV5200 Bedienungsanleitung

If you fill the tank manually, pay attention to the water level on the back of the air cooler tank (Fig. 5).
When filling in water, follow the minimum and maximum water levels.
Use clean water from the water supply.
Tips: When using the appliance for the first time it is normal that the water in the tank has a faint odour or colour. It is
not toxic, it does not endanger your health.

Using the remote control

1. First open the battery cover on the back of the remote control and insert a 3V battery.
Opening the battery cover: First press the remote control in the direction of arrow 1 as shown in the figure and
release the battery part. Then remove it in the direction of arrow 2.
2. When using the remote, point to the receiver.
3. Once the battery is low, release the battery cover in the direction shown in the figure and replace the battery (3 V).
Observe the battery polarity and replace the battery cover before use.
0 OV5200
Fig. 5
EN
59
