Velleman projects VMB1BL Bedienungsanleitung Seite 3

Relay contacts for blind motor control
1
Direct push button control (COM connection)
2
3 12V supply
Velbus
4
Direct push button control (up and down)
5
6 Up indication LED
Down indication LED
7
Forwarding LED
8
9 Power LED
10 Reception LED
Down operation mode LED
11
12 Up operation mode LED
13 Termination
If the module is connected as the final device on the VELBUS, place the 'TERM' jumper. Remove the jumper in all other cases.
14 Address setting
Enter a unique address (except for 'C1', 'D1', 'E1' and 'F1') for each module.
Switch-off setting
15
16 Manuel down operation
17 Manuel up operation
See also connection examples on page 22 & 23 !
ENGLISH
3
