*There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED
SPEED LED
LAN Port
Activity / Link LED
Status Description
Off No Link
Blinking Data Activity
On Link
** If you use a 2-channel speaker, please connect the speaker's plug into "Front Speaker Jack". See the table below
for connection details in accordance with the type of speaker you use.
Audio Output Front Speaker
Channels (No. 7)
2
4
6
8
***For the further information, please visit www.asrock.com.
Speed LED
Status
Off
Orange
Green
Rear Speaker
(No. 5)
V --
V V
V V
V V
X570 Phantom Gaming-ITX/TB3
Description
10Mbps connection
100Mbps connection
1Gbps connection
Central / Bass Line In
(No. 4) (No. 6)
--
--
V
V
--
--
--
V
