2.4 Expansion Slots (PCI Express Slots)
There is 1 PCI Express slot on the motherboard.
Before installing an expansion card, please make sure that the power supply is switched off
or the power cord is unplugged. Please read the documentation of the expansion card and
make necessary hardware settings for the card before you start the installation.
PCIe slots:
PCIE1 (PCIe 4.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIe Slot Configurations
Ryzen Series CPUs (Matisse)
Ryzen Series CPUs (Pinnacle Ridge)
Ryzen Series CPUs (Picasso)
For a better thermal environment, please connect a chassis fan to the motherboard's
chassis fan connector (CHA_FAN1/WP ) when using multiple graphics cards.
22
PCIE1
Gen4x16
Gen3x16
Gen3x8
