ASROCK X570 Phantom Gaming-ITX/TB3 Bedienungsanleitung Seite 30

Addressable LED Header
(3-pin ADDR_LED1)
(see p.1, No. 6)
X570 Phantom Gaming-ITX/TB3
This header is used to connect
GND
Addressable LED extension cable
DO_ADDR which allows users to choose
VOUT
from various LED lighting
1
effects.
Caution: Never install the
Addressable LED cable in the
wrong orientation; otherwise,
the cable may be damaged.
*Please refer to page 32 for
further instructions on this
header.
27
