Prestigio Data Racer I Kurzanleitung Seite 4

NOTE:
Please proceed to step 5 if your operating system is not
Windows Vista.
4. Click on Allow option in the User Account Control
dialog box prompted.
5. Please enter the serial key number obtained from the last
page of quick guide.
6. Click on Install button to start installation process. Click
on Back button to return to previous page and Cancel
button to stop process.
7. After the software installation is successfully completed,
Please remove Data Racer I and reconnect it to your PC
again.
8. Upon successful installation and activation, TurboHDD
software interface will pop up automatically.
3.2 Using Software
1. Click on desktop shortcut "TurboHDD USB" or click on
Start > Program Files > "TurboHDD USB" > "TurboHDD
USB" to initiate software.
2. Upon entering the main menu, detailed information
of Hard Disk Enclosure is
displayed at the bottom of
the interface. The software
is set at Turbo mode by
default.
3. Click on "Hard Disk" image
to toggle between Turbo and
Normal mode.
•
Turbo mode: The
software accelerates data
transmission speed and
efficiency.
•
Normal mode: Data
transmission maintains
normal speed unaided.
3
3.3 To Safely Remove Device
1. Click on USB Cable image located to the side of Hard
Disk image to safely remove Hard Disk Enclosure from PC.
2. Click on Yes button to confirm removal or No button to
cancel action.
3. The USB cable image is now disconnected from "hard
disk" image. The hard disk is safely disconnected from PC.
4. To execute the software again, simply physically disconnect
the hard disk enclosure and connect it to PC again.
4. Product Specifications
Product Feature Prestigio Data Racer I USB2.0/eSATA
External HDD Enclosure
•
Interface
USB2.0 Interface (Max 480mbps)
•
eSATA Interface (Max 3.0Gbps)
HDD Type 2.5" 7200RPM HDD or 5400RPM HDD
HDD Capacity 320/500GB+
Power Supply Directly from USB port
Software Included TurboHDD USB Software
PLEASE REFER TO FULL MANUALS IN DATA RACER I
FOLDER FOR MORE DETAILED DEVICE OPERATION
INSTRUCTIONS
DataRacer I
